Model
HUANANZHI X99-AD3 Motherboard
Main chipset
Inte C612
CPU Socket
Support LGA2011-3 Processor(Xeon E5 2629 v3/ E5-2649 v3/E5-2669 v3/E5-2673 v3/ E5-2676 v3/E5-2678 v3/E5-2696 v3/E5-2666 v3/E5-2686v4/E5-2696v4)
Memory slot
4 x DDR3memory slot
Memory standard
Support Four channels DDR3 1866/1600/1333MHz，Max support 128GB
Storage interface
6 x SATA3.06Gbps，2xSSATA3.06Gbps
Expansion Slots
2xPCI Express3.0X16，1xPCIExpress3.0x4，1xPCI Express2.0x1
Expansion interface
1xM.2 22110 NVME PCIEX43.0 32Gbps，1xM.2 2280NGFF SATA3.06Gbps
Soud Track
5.1
Network Card
Gigabit Ethernet
Power interface
24pin+8pin
FAN PIN
1xCPU_FAN PIN，3xSYS_FAN PIN
power supply
6-phase power supply
PCB layers
10-layer PCB
Dimension
283*215MM ATX
Rear panel interface
PS/2 Mouse and Keyboard port，6xUSB2.0，4xUSB3.0，1x Network card interface，1x3-hole audio interface
Front panel interface
1 x USB2.0 PIN，1 x USB3.0 PIN，1 x Front audio pin，1xCOM pin，1xMotherboard buzzer，1xpost card，1xStart/restart button
Support system
Windows7 Windows10 Windows11
BIOS
AMI UEFI BIOS
Packing list
1 x Motherboard，1 x SATA data cable，1xWarranty card
-
X99-AD3 Motherboard Drive Download
X99-AD3 Motherboard BIOS(22-07-25) Download
X99-AD3 Sound card driver Download
-
User Manual
Installation video
HUANANZHI X99-AD3 Motherboard（MOS）
· Support LGA2011-3 Processor(Xeon E5 2629 v3/ E5-2649 v3/E5-2669 v3/E5-2673 v3/ E5-2676 v3/E5-2678 v3/E5-2696 v3/E5-2666 v3/E5-2686v4/E5-2696v4)
· 4 x DDR3memory slot，Max support 128GB
· Four channels DDR3 1866/1600/1333MHz
· 2xPCI Express3.0X16，1xPCIExpress3.0x4，1xPCI Express2.0x1
· 1xM.2 22110 NVME PCIEX43.0 32Gbps，1xM.2 2280NGFF SATA3.06Gbps
· 6xUSB2.0，4xUSB3.0，1 x USB2.0 PIN，1 x USB3.0 PIN
